Polyester Air Slide Fabric, Belt

Polyester Air Slide Fabric, Belt

we produce the air slide fabric for conveyance of dry bulk powders, we accept customization for your machine.First grade quality and competitive price to let our products share a good reputation all over the world. We also accept customization.
Capacity: 500 ㎡/ mouth.
Max Width: 2.6 m.
Thickness: 4~10 mm.
Heat-resistant: 160 ℃ ~ 200 ℃.

  • Description
  • Reviews (0)

Description

Specification sheet of  polyester Airslide Fabric:

Product Name PE Air slide Fabric
Thickness( mm ) 4 ~ 10
Gram Weight( gsm ) 3200 -7600
Air permeability( L/m2.s ) 65 ~ 100
Elongation

(Strength: 2000 N / 2 cm )

Warp 1.4 ~ 2.5 %
Weft 0.65 ~ 1.2 %
Max. Operating Temp. 160 ℃ ( 320 ℉)
Ultimate Temp.( Instant ) 200 ℃ ( 392 ℉)
Number of plies 5

Ps: Tolerance of thickness: +/- 0.3mm , gram weight: +/- 5%, air permeability: +/- 10%.

Air slide Fabrics are air permeable fabrics used in air activated conveyors or bin/silo aerators for the conveyance of dry bulk powders. It is also be called air slide belt, air slide cloth, air slide canvas, air slide membrane. We have the most advanced equipment, same as every other respected competitors. We can produce the best products, same as every other respected competitors.

We supply two kinds of Airslide Fabric:

Filament Polyester Airslide Fabric Spun Polyester Airslide Fabric

Our Airslide Fabric has great performances of tensile strength, air permeability, service life, and heat-resistance. The Airslide Fabric is better than spun cloth in these areas.

Applications of Airslide Fabric

Our product mainly used in air activated conveyors or bin/silo aerators for the conveyance of dry bulk powders. Cement industry: cement bulk cement trucks,boats; Mining: alumina,lime,fly ash,phosphate; Chemical industry: soda; Power: fly ash, desulfurization; Food industry: flour.
